AED Defibrilator IPAD Cusp2 (Intelligent Public Access)

AED Defibrilator IPAD Cusp2 (Intelligent Public Access)

Features:

• Ambient noise detection [Auto volume adjusting]
• Easy-to-use & manage Electrode (Displaying Life expectancy of Electrode)
• Graphic LCD status Indicator (Device, Pads & Battery)
• Selectable Voice guide for both Lay Rescuer and Healthcare provider
• ECG monitoring or multi printing via Bluetooth communication

Product Exterior

• Dimensions: 260 x 256 x 70 mm (Width x Length x Height)
• LCD: 5inch wide, 480×272 16bit
• Weight 2.4㎏ (Including the battery pack and pads)

Defibrillator

• Operation Type: Dual Mode (semi-automated, manual) External Defibrillator
• Output Type: e-cube biphasic (Truncated exponential type) output Energy
• AED Mode
• 150J±4J, 200J±6J at 50Ω load for adults
• 50J±2J at 50Ω load for children
• Manual Mode
• 2J±1J, 3J±1J, 5J±1J, 7J±1J, 10J±1J, 20J±2J, 30J±2J, 50J±2J, 70J±2J, 100J±4J, 150J±4J, 200J±6J at 50Ω load

Self Test

• Auto Power Self-Test / Real-time Self-Test
• Daily / Weekly / Monthly Self-Test
• Manual Battery Pack Self-Test (performed when the user inserts the battery pack)

ECG Analysis System

• Analyzes whether the rhythms of the patient’s impedance and ECG require a defibrillation
• Measured Impedance Range 25Ω ~ 175Ω

Battery

• + Type : DC 12 Volt 2.8 Ah, Lithium manganese dioxide
• + Capacity : Minimum 100shocks (150J )

High Capacity

• + Type : DC 12Volt 4.2Ah, Lithium manganese dioxide
• + Capacity : Minimum 200shocks (150J )
• Lifespan 5 years (High capacity battery)(With the condition of the temperature of operation/standby, standby mode after the first initial check)

Electrode

• Adult: Electrode Area: 110 cm2
• Cable Length: Total 120cm (Internal: 95cm, External: 25cm)
• Pediatric: Electrode Area: 50 cm2
• Cable Length: Total 120cm (Internal: 80cm, External: 40cm)

Data Storage and Transfer

• Data Storage: Saves 3 events on the internal memory (up to 17 hours per event)
• SD Card: Stores the ECG and event data from the device’s internal memory through the PC software (CU-Expert).
• Bluetooth: Uses Bluetooth to communicate with the Printer or the CUEM1
• (ECG transmission device)

The product images shown are for illustration purposes only and may not be an exact representation of the product.
